| Model | DC voltage | Rated current | Current range | DC output power | Ripple & Noise (max) | Load regulation | Linear adjustment rate | Efficiency (Typ.) |
|---|---|---|---|---|---|---|---|---|
| DY-60W-12-HL7 | 12V±5% | 5A | 0-5A | 60W | <250mV | 1% | 1% | >86.1% |
| DY-60W-24-HL7 | 24V±5% | 2.5A | 0-2.5A | 60W | <250mV | 1% | 1% | >88.3% |
| Model | Voltage range | Frequency range | AC current (Typ.) | Cold cranking current | Power factor (Typ.) |
|---|---|---|---|---|---|
| DY-100W-12-HL7 | 180-250V AC | 50-60Hz | 0.5A 230V | 17A / 230VAC | PF<0.6 |
| DY-100W-24-HL7 | 180-250V AC | 50-60Hz | 0.5A 230V | 17A / 230VAC | PF<0.6 |
| Model | Pressure resistance | Insulation resistance |
|---|---|---|
| DY-100W-12-HL7 | Between input and output: AC2.5KV 5mA 60S; | Between input and output: 100Mohms/500VDC/25℃h |
| Between input and shell: AC2KV 5mA60S |
