| Model | DC voltage | Rated current | Current range | DC output power | Ripple &Noise (max) | load regulation | linear adjustment rate | Efficiency (Typ.) |
|---|---|---|---|---|---|---|---|---|
| DY-200W-12-HL7 | 12V±5% | 16.7A | 0-16.7A | 200W | <250mV | 1% | 1% | >88.1% |
| DY-200W-24-HL7 | 24V±5% | 8.3A | 0-8.3A | 200W | <250mV | 1% | 1% | >90.1% |
| Model | Voltage range | Frequency range | AC current(Typ.) | Cold cranking current | Power factor(Typ.) |
|---|---|---|---|---|---|
| DY-400W-12-HL7 | 180-250V AC | 50-60Hz | 2A 230V | 28A/230VAC | PF<0.6 |
| DY-400W-24-HL7 | 180-250V AC | 50-60Hz | 2A 230V | 28A/230VAC | PF<0.6 |
| Model | Pressure resistance | Insulation resistance |
|---|---|---|
| DY-400W-12-HL7 | Between input and output: AC2.5KV 5mA 60S; | Between input and output: 100M ohms/500VDC/25� |
| Between input and shell: AC2KV 5mA 60S |
