APPLICATIONS
It is used as EIB instabus communication cable in smart building systems. The cable with a static screen is protected against electromagnetic interference from the environment. In KNX compatible home and building electronic systems (HBES), which provides automatic, central or remote control of heating, cooling and ventilation, lighting, motorized blinds, audio video, CCTV, fire detection, security, intercom systems in dry or humid places in indoor environment fixed installations. used
CABLE CONSTRUCTION
| Inner Conductor | Anneoled Copper Wire Q 24 AWG |
| Insulation | HDPE TIA 568 Insulation Color Code |
| Stranding | 4 Pairs Twisted & Stranded |
| screen | Tinned Copper Wire Braid + Al-Pet Foil |
| Sheath | PVC: GREY / LSZH: YELLOW / PE: BLACK |
| Product Types | U/UTP - Un-Shielded F/UTP - Foil Shielded SF/UTP - Foil +Copper |
| code | section | conductor mm | Insulation Diameter mm |
Insulation Wall Thickness mm |
Sheath Diameter mm |
Sheath Wall Thickness mm |
Copper Weight kg/km |
| 11232 | 2x2x0.80 | 0.80 | 1.60 | 0.40 | 6.20 | 1.00 | 23.5 |
| 11231 | 1x2x0.80 | 0.80 | 1.60 | 0.40 | 5.40 | 1.00 | 13.5 |
STANDARTS:
YANGIN PERFORMANSLARI (FIRE PERFORMANCE):
